Armoured Floating Hose

Dredging armored floating hoses represent a cutting-edge innovation in the dredging industry, combining the advantages of self-floating hoses and armored discharge hoses. Designed for durability, abrasion resistance, and ease of use, these hoses are ideal for transporting large volumes of heavy, abrasive, and sharp-edged materials in demanding dredging and mining operations.

Structure

Feature

1. Enhanced Wear Resistance
·Built on the foundation of ordinary mainline floating hoses, these hoses feature a wear-resistant steel ring embedded inside the wear-resistant layer. This design significantly improves abrasion resistance, making them ideal for transporting abrasive materials such as coral reefs, sharp soil, gravel, and other heavy or sharp-edged substances. ·The inclusion of a color indication layer in the inner lining allows for easy monitoring of wear and tear.

2.Robust Outer Cover
The outer layer is reinforced with embedded cords for added strength and UV resistance, ensuring durability in harsh environmental conditions, including prolonged exposure to sunlight and seawater.

3. Wide Range of Sizes and Pressure Ratings
·Available in inner diameters (ID) ranging from 300 mm to 1200 mm, catering to various project requirements.
·Designed to handle working pressures from 10 bar to 40 bar, making them versatile for different dredging and mining applications.

Advantage

1.Durability: The embedded steel rings and high-abrasion-resistant rubber significantly enhance wear resistance, reducing the frequency of replacements.
2.Cost-Effectiveness: Longer service life and lower maintenance requirements translate to reduced operational costs.
3.Versatility: Suitable for a wide range of materials, pressures, and environmental conditions, including the transport of highly abrasive substances like coral reefs and sharp soil.

Application

Specification

ID		Pressure BAR		Length MM
MM	Inch	WP	BP	Length MM
150	6	10-35	30-105	11800
200	8	10-35	30-105	11800
250	10	10-35	30-105	11800
300	12	10-35	30-105	11800
350	14	10-35	30-105	11800
400	16	10-35	30-105	11800
450	18	10-35	30-105	11800
500	20	10-35	30-105	11800
600	24	10-35	30-105	11800
650	26	10-35	30-105	11800
700	28	10-35	30-105	11800
750	30	10-35	30-105	11800
800	32	10-35	30-105	11800
850	34	10-35	30-105	11800
900	36	10-35	30-105	11800
1000	40	10-35	30-105	11800
1100	44	10-35	30-105	11800
1200	48	10-35	30-105	11800
Note: Specifications, pressures, colors, and other parameters can be customized to meet the customer’s specific requirements.
