Armoured Dredging Discharge Hose

Armored discharge hoses are specifically designed for dredging operations, capable of transporting abrasive, large-volume, and heavy-density materials. These hoses are ideal for handling challenging substances such as coral reef fragments, coarse grit, and weathered rock.

Structure

Feature

1.Structural Integrity:
·Integrated square steel ring reinforcement
·High dimensional stability
·Exceptional resistance to impact loads
2.Material Performance:
·Built-in wear-resistant metal lining
·Superior abrasion resistance
·Excellent flexing resistance
·Pressure-resistant inner layer
3.Operational Specifications:
·Inner diameter range: Up to 1200mm
·Wall thickness: 15mm to 100mm
·Working angle: 0° to 45°
·Custom lengths and pressure ranges available
4.Functional Advantages:
·Easy installation and maintenance
·Enhanced operational safety
·Flexible deployment in various configurations

Advantage

Application

Armored discharge hoses are specifically engineered for demanding dredging operations, ideal for transporting abrasive, large-volume, and heavy-density materials including:
·Mineral ores and slurries
·Diamond ore concentrates
·Coral reef fragments
·Coarse sand and grit
·Weathered rock formations

Specification

ID		Pressure BAR		Length MM
MM	Inch	WP	BP	Length MM
150	6	10-35	30-105	11800
200	8	10-35	30-105	11800
250	10	10-35	30-105	11800
300	12	10-35	30-105	11800
350	14	10-35	30-105	11800
400	16	10-35	30-105	11800
450	18	10-35	30-105	11800
500	20	10-35	30-105	11800
600	24	10-35	30-105	11800
650	26	10-35	30-105	11800
700	28	10-35	30-105	11800
750	30	10-35	30-105	11800
800	32	10-35	30-105	11800
850	34	10-35	30-105	11800
900	36	10-35	30-105	11800
1000	40	10-35	30-105	11800
1100	44	10-35	30-105	11800
1200	48	10-35	30-105	11800
Note: Specifications, pressures, colors, and other parameters can be customized to meet the customer’s specific requirements.
